Inline насосы с электронным управлением Wilo DL-E
Отличительные особенности:
• Одноступенчатый центробежный сдвоенный насос со скользящим торцевым уплотнением
• Стандартный мотор со встроенным частотным преобразователем соединен с насосной частью через муфту
| Модель | Макс. расход (Q max), м³/ч | Макс. напор (H max), м | Макс. рабочее давление (P max), бар | Температура жидкости, °C |
| DL-E 40/170-5,5/2 | 41 | 41 | 16 | -20......+140 |
| DL-E 40/170-5,5/2-R1 | 41 | 41 | 16 | -20......+140 |
| DL-E 40/200-7,5/2 | 35 | 51 | 16 | -20......+140 |
| DL-E 40/200-7,5/2-R1 | 35 | 52 | 16 | -20......+140 |
| DL-E 40/220-11/2 | 40 | 65 | 16 | -20......+140 |
| DL-E 40/220-11/2-R1 | 40 | 67 | 16 | -20......+140 |
| DL-E 50/160-5,5/2 | 55 | 33 | 16 | -20......+140 |
| DL-E 50/160-5,5/2-R1 | 55 | 33 | 16 | -20......+140 |
| DL-E 50/170-7,5/2 | 65 | 39 | 16 | -20......+140 |
| DL-E 50/170-7,5/2-R1 | 65 | 39 | 16 | -20......+140 |
| DL-E 50/180-7,5/2 | 38 | 45 | 16 | -20......+140 |
| DL-E 50/180-7,5/2-R1 | 38 | 45 | 16 | -20......+140 |
| DL-E 50/210-11/2 | 56 | 55 | 16 | -20......+140 |
| DL-E 50/210-11/2-R1 | 56 | 55 | 16 | -20......+140 |
| DL-E 50/220-15/2 | 65 | 65 | 16 | -20......+140 |
| DL-E 50/220-15/2-R1 | 240 | 15 | 16 | -20......+140 |
| DL-E 65/150-5,5/2 | 75 | 25 | 16 | -20......+140 |
| DL-E 65/150-5,5/2-R1 | 75 | 25 | 16 | -20......+140 |
| DL-E 65/160-7,5/2 | 75 | 33 | 16 | -20......+140 |
| DL-E 65/160-7,5/2-R1 | 75 | 32 | 16 | -20......+140 |
| DL-E 65/170-11/2 | 85 | 40 | 16 | -20......+140 |
| DL-E 65/170-11/2-R1 | 85 | 40 | 16 | -20......+140 |
| DL-E 65/200-15/2 | 82 | 52 | 16 | -20......+140 |
| DL-E 65/200-15/2-R1 | 83 | 53 | 16 | -20......+140 |
| DL-E 65/210-18,5/2 | 90 | 62 | 16 | -20......+140 |
| DL-E 65/210-18,5/2-R1 | 90 | 62 | 16 | -20......+140 |
| DL-E 65/220-22/2 | 100 | 70 | 16 | -20......+140 |
| DL-E 65/220-22/2-R1 | 100 | 70 | 16 | -20......+140 |
| DL-E 80/130-5,5/2 | 90 | 18 | 16 | -20......+140 |
| DL-E 80/130-5,5/2-R1 | 90 | 19 | 16 | -20......+140 |
| DL-E 80/140-7,5/2 | 90 | 22 | 16 | -20......+140 |
| DL-E 80/140-7,5/2-R1 | 110 | 22 | 16 | -20......+140 |
| DL-E 80/150-7,5/2 | 85 | 26 | 16 | -20......+140 |
| DL-E 80/150-7,5/2-R1 | 85 | 26 | 16 | -20......+140 |
| DL-E 80/160-11/2 | 130 | 32 | 16 | -20......+140 |
| DL-E 80/160-11/2-R1 | 130 | 32 | 16 | -20......+140 |
| DL-E 80/170-15/2 | 120 | 41 | 16 | -20......+140 |
| DL-E 80/170-15/2-R1 | 120 | 41 | 16 | -20......+140 |
| DL-E 80/190-18,5/2 | 132 | 50 | 16 | -20......+140 |
| DL-E 80/190-18,5/2-R1 | 131 | 50 | 16 | -20......+140 |
| DL-E 80/200-22/2 | 143 | 53 | 16 | -20......+140 |
| DL-E 80/200-22/2 R1 | 145 | 54 | 16 | -20......+140 |
| DL-E 100/145-11/2 | 190 | 23 | 16 | -20......+140 |
| DL-E 100/145-11/2-R1 | 190 | 23 | 16 | -20......+140 |
| DL-E 100/150-15/2 | 260 | 27 | 16 | -20......+140 |
| DL-E 100/150-15/2-R1 | 260 | 27 | 16 | -20......+140 |
| DL-E 100/160-18,5/2 | 260 | 30 | 16 | -20......+140 |
| DL-E 100/160-18,5/2-R1 | 260 | 30 | 16 | -20......+140 |
| DL-E 100/165-22/2 | 240 | 33 | 16 | -20......+140 |
| DL-E 100/165-22/2-R1 | 240 | 33 | 16 | -20......+140 |
| DL-E 100/220-5,5/4 | 125 | 14 | 16 | -20......+140 |
| DL-E 100/220-5,5/4-R1 | 125 | 14 | 16 | -20......+140 |
| DL-E 100/250-7,5/4 | 145 | 18 | 16 | -20......+140 |
| DL-E 100/250-7,5/4-R1 | 145 | 19 | 16 | -20......+140 |
| DL-E 100/270-11/4 | 180 | 25 | 16 | -20......+140 |
| DL-E 100/270-11/4-R1 | 180 | 25 | 16 | -20......+140 |
| DL-E 125/210-5,5/4 | 145 | 12 | 16 | -20......+140 |
| DL-E 125/210-5,5/4-R1 | 150 | 11 | 16 | -20......+140 |
| DL-E 125/220-7,5/4 | 160 | 14 | 16 | -20......+140 |
| DL-E 125/220-7,5/4-R1 | 160 | 14 | 16 | -20......+140 |
| DL-E 150/190-5,5/4 | 185 | 9 | 16 | -20......+140 |
| DL-E 150/190-5,5/4-R1 | 190 | 9 | 16 | -20......+140 |
| DL-E 150/200-7,5/4 | 190 | 11 | 16 | -20......+140 |
| DL-E 150/200-7,5/4-R1 | 190 | 11 | 16 | -20......+140 |
| DL-E 150/220-11/4 | 240 | 15 | 16 | -20......+140 |
| DL-E 150/220-11/4-R1 | 240 | 15 | 16 | -20......+140 |
| DL-E 150/250-15/4 | 270 | 18 | 16 | -20......+140 |
| DL-E 150/250-15/4-R1 | 270 | 18 | 16 | -20......+140 |
| DL-E 150/260-18,5/4 | 285 | 20 | 16 | -20......+140 |
| DL-E 150/260-18,5/4-R1 | 280 | 20 | 16 | -20......+140 |
| DL-E 150/270-22/4 | 350 | 24 | 16 | -20......+140 |
| DL-E 150/270-22/4-R1 | 350 | 23 | 16 | -20......+140 |
| DL-E 200/240-15/4 | 375 | 15 | 16 | -20......+140 |
| DL-E 200/240-15/4-R1 | 380 | 15 | 16 | -20......+140 |
| DL-E 200/250-18,5/4 | 390 | 17 | 16 | -20......+140 |
| DL-E 200/250-18,5/4-R1 | 390 | 17 | 16 | -20......+140 |
| DL-E 200/260-22/4 | 450 | 18 | 16 | -20......+140 |
| DL-E 200/260-22/4-R1 | 450 | 18 | 16 | -20......+140 |
